Flexible Eca-s1a,d1,a1 grounding cable for commercial and industrial installations
Suitable for grounding applications in commercial and industrial switchgear, distribution panels, and protective earth circuits. Ideal for protected or semi-protected indoor environments.
PVC insulation provides excellent mechanical flexibility, flame-retardant properties, and reliable performance over -5°C to +70°C. Ensures safe and durable grounding connections.
Ecas1a,d1,a1 CPR-rated and compliant with EN50525, EN50575, CE, RoHS, and REACH. Guarantees adherence to regulatory safety requirements and reduced project risk.
| Description | Nominal cross section m㎡ | OD of conductor mm | Thickness of insulation mm | Diameter of cable mm | Approx. weight kg/km | Cable Color |
|---|---|---|---|---|---|---|
| H05V2-K | 0.5 | 0.95 | 0.6 | 2.15 | 8.5 |  |
| H05V2-K | 0.75 | 1.15 | 0.6 | 2.35 | 11 | |
| H05V2-K | 1.0 | 1.3 | 0.6 | 2.5 | 13.5 | |
| H05V2-K | 1.5 | 1.6 | 0.7 | 3.0 | 19.5 | |
| H05V2-K | 2.5 | 2.0 | 0.8 | 3.6 | 30.5 | |
| H05V2-K | 4 | 2.5 | 0.8 | 4.1 | 43.5 | |
| H05V2-K | 6 | 3.1 | 0.8 | 4.7 | 62 | |
| H05V2-K | 10 | 4.1 | 1.0 | 6.1 | 106 | |
| H05V2-K | 16 | 5.5 | 1.0 | 7.5 | 160 | |
| H05V2-K | 25 | 6.7 | 1.2 | 9.1 | 246 | |
| H05V2-K | 35 | 8.2 | 1.2 | 10.6 | 339 | |
| H05V2-K | 50 | 10.0 | 1.4 | 12.8 | 483 | |
| H05V2-K | 70 | 11.6 | 1.4 | 14.4 | 668 | |
| H05V2-K | 95 | 13.0 | 1.6 | 16.2 | 877 | |
| H05V2-K | 120 | 14.4 | 1.6 | 17.6 | 1136 | |
Download TDS
Yes. Send the exact cable designation and, where possible, the existing datasheet or project specification. We compare conductor material, construction, voltage rating, standards and the requirements that affect the installation before confirming whether an equivalent can be offered.
Send the exact requirement. The website does not represent every possible production combination. We will check whether the construction can be supplied and whether the required standards or certification scope also cover that version before it is quoted.
Requested drum lengths can be reviewed with the cable schedule. What is practical depends on cable dimensions and weight, total quantity, drum capacity and transport or site-handling limits, so the required lengths should be included with the enquiry.
No single MOQ applies across the entire range. The practical quantity depends on the cable type, size, construction, packing and production conditions. Send the actual cable list and quantities and we can confirm the applicable requirement for those items.
