Durable medium-voltage cable for industrial and commercial power distribution
Suitable for commercial and industrial energy distribution, including underground conduits, direct burial, or exposed routing in substations. HDPE sheath recommended for UV-exposed outdoor areas; MDPE for buried installations.
XLPE insulation and metallic sheath ensure high dielectric strength and mechanical robustness. UV-resistant and moisture-proof, with long-term reliability in medium-voltage networks.
Certified by CE, RoHS, and REACH. Meets international medium-voltage electrical and fire safety standards to minimize project risk and ensure regulatory compliance.
| Description | Cross Section m㎡ |
OD of conductor mm | Thickness of Semi- con . layer Inner mm | Thickness of Semi- con . layer Outer mm | Thickness of Insulation mm | Wire Screen cross section m㎡ |
Tape Screen Thickness mm | Thickness of Sheath mm | Cable overall diameter mm | Cable weight kg/km |
|---|---|---|---|---|---|---|---|---|---|---|
| NA2XS(F)2Y 12/20(24)kV | 1 x 50 | 8.1 | 0.7 | 0.7 | 5.5 | 16 | 0.1 | 1.8 | 27 | 700 |
| NA2XS(F)2Y 12/20(24)kV | 1 x 70 | 9.7 | 0.7 | 0.7 | 5.5 | 16 | 0.1 | 1.9 | 29 | 800 |
| NA2XS(F)2Y 12/20(24)kV | 1 x 95 | 11.4 | 0.7 | 0.7 | 5.5 | 16 | 0.1 | 1.9 | 31 | 900 |
| NA2XS(F)2Y 12/20(24)kV | 1 x 120 | 12.7 | 0.7 | 0.7 | 5.5 | 16 | 0.1 | 2 | 32 | 1000 |
| NA2XS(F)2Y 12/20(24)kV | 1 x 150 | 14.5 | 0.7 | 0.7 | 5.5 | 25 | 0.1 | 2 | 34 | 1300 |
| NA2XS(F)2Y 12/20(24)kV | 1 x 185 | 15.9 | 0.7 | 0.7 | 5.5 | 25 | 0.1 | 2.1 | 36 | 1400 |
| NA2XS(F)2Y 12/20(24)kV | 1 x 240 | 18.6 | 0.7 | 0.7 | 5.5 | 25 | 0.1 | 2.1 | 38 | 1600 |
| NA2XS(F)2Y 12/20(24)kV | 1 x 300 | 20.7 | 0.7 | 0.7 | 5.5 | 25 | 0.1 | 2.2 | 42 | 1900 |
| NA2XS(F)2Y 12/20(24)kV | 1 x 400 | 23.5 | 0.7 | 0.7 | 5.5 | 35 | 0.1 | 2.3 | 45 | 2250 |
| NA2XS(F)2Y 12/20(24)kV | 1 x 500 | 26.5 | 0.7 | 0.7 | 5.5 | 35 | 0.1 | 2.4 | 48 | 2750 |
| NA2XS(F)2Y 12/20(24)kV | 1 x 630 | 30.2 | 0.7 | 0.7 | 5.5 | 35 | 0.1 | 2.5 | 52 | 3250 |
Download TDS
Yes. Send the exact cable designation and, where possible, the existing datasheet or project specification. We compare conductor material, construction, voltage rating, standards and the requirements that affect the installation before confirming whether an equivalent can be offered.
Send the exact requirement. The website does not represent every possible production combination. We will check whether the construction can be supplied and whether the required standards or certification scope also cover that version before it is quoted.
Requested drum lengths can be reviewed with the cable schedule. What is practical depends on cable dimensions and weight, total quantity, drum capacity and transport or site-handling limits, so the required lengths should be included with the enquiry.
No single MOQ applies across the entire range. The practical quantity depends on the cable type, size, construction, packing and production conditions. Send the actual cable list and quantities and we can confirm the applicable requirement for those items.
