H1Z2Z2-K 1.5 kV DC solar cable with a nylon barrier beneath the outer sheath for PV routes that need a non-metallic physical defence against rodent damage.
H1Z2Z2-K 1.5 kV DC solar cable with external steel-wire armour for fixed PV routes exposed to severe rodent activity or mechanical damage.
H1Z2Z2-K 1.5 kV DC solar cable with a capsaicin-based rodent-deterrent sheath for PV routes where chemical protection is preferred over added armour.
Factory-terminated PV extension cable for controlled module, string and combiner-box connections.
Joined twin PV cable for orderly positive and negative string routing beneath solar modules.
Single-core PV cable for reliable DC wiring across rooftop and ground-mounted solar arrays.
Durable DC connector for residential solar panels – UV-resistant and waterproof.
Reliable DC connection for residential photovoltaic systems, UV-resistant, waterproof, and long-lasting.
Solid 450/750 V PVC wire for stable fixed circuits in protected conduit and building installations.
Class 2 stranded 300/500 V PVC wire for fixed equipment and panel routes needing moderate flexibility.
Solid 300/500 V PVC wire for simple, stable fixed connections inside protected equipment and conduit.
Class 2 stranded 450/750 V PVC wire for protected fixed routes requiring easier pulling and forming.
300/500 V PVC-sheathed cable for fixed surface and flush-mounted installations in Finnish building wiring.
Flexible 300/500 V PVC wire for compact equipment, switchgear and control-panel connections.
Flexible 450/750 V PVC wire for protected conduit, panel and grounding connections.
Flexible PVC insulated earthing cable for residential solar PV system grounding
Green/yellow H07V-K grounding lead with factory-crimped ring / OT terminal for ready-to-install earthing and bonding connections.
Bare 25 mm² Class 2 stranded copper conductor for earthing, grounding and equipotential bonding.
Flexible 450/750 V PVC wire for protected conduit, panel and grounding connections.
H1Z2Z2-K 1.5 kV DC solar cable with a nylon barrier beneath the outer sheath for PV routes that need a non-metallic physical defence against rodent damage.
H1Z2Z2-K 1.5 kV DC solar cable with external steel-wire armour for fixed PV routes exposed to severe rodent activity or mechanical damage.
H1Z2Z2-K 1.5 kV DC solar cable with a capsaicin-based rodent-deterrent sheath for PV routes where chemical protection is preferred over added armour.
Factory-terminated PV extension cable for controlled module, string and combiner-box connections.
Joined twin PV cable for orderly positive and negative string routing beneath solar modules.
Single-core PV cable for reliable DC wiring across rooftop and ground-mounted solar arrays.
Flexible PVC insulated earthing cable for residential solar PV system grounding
Green/yellow H07V-K grounding lead with factory-crimped ring / OT terminal for ready-to-install earthing and bonding connections.
Bare 25 mm² Class 2 stranded copper conductor for earthing, grounding and equipotential bonding.
Flexible 450/750 V PVC wire for protected conduit, panel and grounding connections.
Flexible Eca-s1a,d1,a1 grounding cable for commercial and industrial installations
Flexible PVC insulated earthing cable for residential solar PV system grounding
Solid 450/750 V PVC wire for stable fixed circuits in protected conduit and building installations.
Class 2 stranded 300/500 V PVC wire for fixed equipment and panel routes needing moderate flexibility.
Solid 300/500 V PVC wire for simple, stable fixed connections inside protected equipment and conduit.
Class 2 stranded 450/750 V PVC wire for protected fixed routes requiring easier pulling and forming.
300/500 V PVC-sheathed cable for fixed surface and flush-mounted installations in Finnish building wiring.
Flexible 300/500 V PVC wire for compact equipment, switchgear and control-panel connections.
Flexible 450/750 V PVC wire for protected conduit, panel and grounding connections.
High-performance medium-voltage cable for demanding industrial and commercial networks
High-performance medium-voltage cable for demanding industrial and commercial networks
High-performance medium-voltage cable for demanding industrial and commercial networks
Reliable medium-voltage cable for commercial and industrial energy networks
Durable medium-voltage cable for industrial and commercial power distribution
XLPE Insulated Aluminum Conductor 0.6/1 kV Power Cable
XLPE Insulated and PVC Sheathed 0.6/1 kV Power Cable for Commercial & Industrial Distribution
XLPE Insulated and PVC Sheathed Heavy-Duty Power Cable for Commercial & Industrial Applications
Halogen-Free XLPE Insulated 0.6/1 kV Power Cable
Copper Conductor Wire Armored Cable for Industrial & Commercial Installations
Copper Conductor Concentric Cable for Industrial & Commercial Installations
Aluminum Conductor PVC Insulated 0.6/1 kV Power Cable
hot search
Copper Conductor Wire Armored Cable for Industrial & Commercial Installations
Galvanized steel wire armor shields the cable against mechanical stress, ensuring safe operation in industrial environments.
The concentric copper conductor serves as a protective earth, offering an extra layer of electrical safety for installers and operators.
PVC or halogen-free insulation provides heat resistance, chemical resistance, and fire safety compliance for industrial and commercial installations.
| Description | Cross Section m㎡ | Conduct or Type mm | Thickness of Insulation mm | Thickness of Inner sheath mm | Screen cross section m㎡ | Thickness of Sheath mm | Cable overall diameter mm | Current carrying capacity In ground 20°C A |
Current carrying capacity In air 30°C A |
Cable weight kg/km |
|---|---|---|---|---|---|---|---|---|---|---|
| NYCWY | 2 x 10 / 10 | RE | 1 | 1 | 10 | 1.8 | 19 | 79 | 60 | 650 |
| NYCWY | 2 x 16 / 16 | RE | 1 | 1 | 16 | 1.8 | 21 | 102 | 80 | 850 |
| NYCWY | 2 x 25 / 25 | RM | 1.2 | 1 | 25 | 1.8 | 24 | 133 | 106 | 1210 |
| NYCWY | 3 x 10 / 10 | RE | 1 | 1 | 10 | 1.8 | 21 | 79 | 60 | 730 |
| NYCWY | 3 x 16 / 16 | RE | 1 | 1 | 16 | 1.8 | 22 | 102 | 80 | 1000 |
| NYCWY | 3 x 25 / 16 | RM | 1.2 | 1 | 16 | 1.8 | 28 | 133 | 106 | 1550 |
| NYCWY | 3 x 25 / 25 | RM | 1.2 | 1 | 25 | 1.8 | 28 | 133 | 106 | 1600 |
| NYCWY | 3 x 35 / 16 | RM | 1.2 | 1 | 16 | 1.9 | 28.5 | 160 | 129 | 1750 |
| NYCWY | 3 x 35 / 35 | SM | 1.2 | 1 | 35 | 1.9 | 28.5 | 160 | 129 | 1850 |
| NYCWY | 3 x 50 / 25 | SM | 1.4 | 1 | 25 | 2 | 31.5 | 190 | 157 | 2250 |
| NYCWY | 3 x 50 / 50 | SM | 1.4 | 1 | 50 | 2 | 31.5 | 190 | 157 | 2450 |
| NYCWY | 3 x 70 / 35 | SM | 1.4 | 1.2 | 35 | 2.1 | 35.5 | 234 | 199 | 2950 |
| NYCWY | 3 x 70 / 70 | SM | 1.4 | 1.2 | 70 | 2.1 | 36.5 | 234 | 199 | 3350 |
| NYCWY | 3 x 95 / 50 | SM | 1.6 | 1.2 | 50 | 2.3 | 40.5 | 280 | 249 | 4100 |
| NYCWY | 3 x 95 / 95 | SM | 1.6 | 1.2 | 95 | 2.3 | 40.5 | 280 | 249 | 4500 |
| NYCWY | 3 x 120 / 70 | SM | 1.6 | 1.2 | 70 | 2.3 | 43.5 | 319 | 289 | 5050 |
| NYCWY | 3 x 120 / 120 | SM | 1.6 | 1.2 | 120 | 2.4 | 44.5 | 319 | 289 | 5550 |
| NYCWY | 3 x 150 / 70 | SM | 1.8 | 1.4 | 70 | 2.5 | 47.5 | 357 | 329 | 6000 |
| NYCWY | 3 x 150 / 150 | SM | 1.8 | 1.4 | 150 | 2.5 | 48.5 | 357 | 329 | 6900 |
| NYCWY | 3 x 185 / 95 | SM | 2 | 1.4 | 95 | 2.6 | 50 | 402 | 377 | 7550 |
| NYCWY | 3 x 185 / 185 | SM | 2 | 1.4 | 185 | 2.6 | 51 | 402 | 377 | 8500 |
| NYCWY | 3 x 240 / 120 | SM | 2.2 | 1.4 | 120 | 2.8 | 57 | 463 | 443 | 9950 |
| NYCWY | 4 x 10 / 10 | RE | 1 | 1 | 10 | 1.8 | 22 | 79 | 60 | 890 |
| NYCWY | 4 x 16 / 16 | RE | 1 | 1 | 16 | 1.8 | 25 | 102 | 80 | 1250 |
| NYCWY | 4 x 25 / 16 | RM | 1.2 | 1 | 16 | 1.9 | 30.5 | 133 | 106 | 1800 |
| NYCWY | 4 x 35 / 16 | SM | 1.2 | 1 | 16 | 2 | 31.5 | 160 | 129 | 2050 |
| NYCWY | 4 x 50 / 25 | SM | 1.4 | 1.2 | 25 | 2.1 | 35.5 | 190 | 157 | 2700 |
| NYCWY | 4 x 70 / 35 | SM | 1.4 | 1.2 | 35 | 2.2 | 39.5 | 234 | 199 | 3750 |
| NYCWY | 4 x 95 / 50 | SM | 1.6 | 1.2 | 50 | 2.3 | 43.5 | 280 | 249 | 5000 |
| NYCWY | 4 x 120 / 70 | SM | 1.6 | 1.4 | 70 | 2.6 | 49.5 | 319 | 289 | 6350 |
| NYCWY | 4 x 150 / 70 | SM | 1.8 | 1.4 | 70 | 2.6 | 51 | 357 | 329 | 7650 |
| NYCWY | 4 x 185 / 95 | SM | 2 | 1.4 | 95 | 2.8 | 56 | 402 | 377 | 9350 |
| NYCWY | 4 x 240 / 120 | SM | 2.2 | 1.6 | 120 | 3 | 62.5 | 463 | 443 | 11600 |
Download TDS
Yes. Send the exact cable designation and, where possible, the existing datasheet or project specification. We compare conductor material, construction, voltage rating, standards and the requirements that affect the installation before confirming whether an equivalent can be offered.
Send the exact requirement. The website does not represent every possible production combination. We will check whether the construction can be supplied and whether the required standards or certification scope also cover that version before it is quoted.
Requested drum lengths can be reviewed with the cable schedule. What is practical depends on cable dimensions and weight, total quantity, drum capacity and transport or site-handling limits, so the required lengths should be included with the enquiry.
No single MOQ applies across the entire range. The practical quantity depends on the cable type, size, construction, packing and production conditions. Send the actual cable list and quantities and we can confirm the applicable requirement for those items.
