XLPE Insulated and PVC Sheathed Heavy-Duty Power Cable for Commercial & Industrial Applications
XLPE insulation improves dielectric properties, reduces power loss, and allows stable operation at higher temperatures. This ensures safe and efficient power delivery for high-demand industrial networks.
Copper conductors with XLPE insulation and PVC sheathing provide mechanical and electrical robustness, protecting against bending stress, UV exposure, and environmental factors. Suitable for industrial, commercial, and infrastructure installations.
Certified to internationally recognized standards, NA2XH cables meet electrical safety regulations and flame-retardant requirements, ensuring reduced project risk and easier regulatory acceptance.
| Description | Cross Section m㎡ |
OD of conductor mm | Thickness of Insulation mm | Thickness of Sheath mm | Cable overall diameter mm | Current Capaciy in air A | Alu weight kg/km | Cable weight kg/km |
|---|---|---|---|---|---|---|---|---|
| NA2XY 0.6/1(1.2)kV | 1 x 25 | 6.3 | 0.9 | 1.4 | 11.7 | 136 | 72.5 | 132 |
| NA2XY 0.6/1(1.2)kV | 1 x 35 | 7.1 | 0.9 | 1.4 | 12.5 | 166 | 101.5 | 166 |
| NA2XY 0.6/1(1.2)kV | 1 x 50 | 8.1 | 1 | 1.4 | 13.6 | 205 | 145 | 211 |
| NA2XY 0.6/1(1.2)kV | 1 x 70 | 9.7 | 1.1 | 1.4 | 15.5 | 260 | 203 | 283 |
| NA2XY 0.6/1(1.2)kV | 1 x 95 | 11.4 | 1.1 | 1.5 | 17.4 | 321 | 275.5 | 376 |
| NA2XY 0.6/1(1.2)kV | 1 x 120 | 12.7 | 1.2 | 1.5 | 19 | 376 | 348 | 456 |
| NA2XY 0.6/1(1.2)kV | 1 x 150 | 14.5 | 1.4 | 1.6 | 22 | 431 | 435 | 560 |
| NA2XY 0.6/1(1.2)kV | 1 x 185 | 15.9 | 1.6 | 1.7 | 23.9 | 501 | 536.5 | 697 |
| NA2XY 0.6/1(1.2)kV | 1 x 240 | 18.6 | 1.7 | 1.8 | 27 | 600 | 696 | 878 |
| NA2XY 0.6/1(1.2)kV | 1 x 300 | 20.7 | 1.8 | 1.9 | 29.5 | 696 | 870 | 1073 |
| NA2XY 0.6/1(1.2)kV | 1 x 400 | 23.5 | 2 | 2 | 32.9 | 821 | 1160 | 1347 |
| NA2XY 0.6/1(1.2)kV | 1 x 500 | 26.5 | 2.2 | 2.1 | 36.6 | 971 | 1450 | 1705 |
| NA2XY 0.6/1(1.2)kV | 1 x 630 | 30.2 | 2.4 | 2.2 | 41 | 1151 | 1827 | 2705 |
Download TDS
Yes. Send the exact cable designation and, where possible, the existing datasheet or project specification. We compare conductor material, construction, voltage rating, standards and the requirements that affect the installation before confirming whether an equivalent can be offered.
Send the exact requirement. The website does not represent every possible production combination. We will check whether the construction can be supplied and whether the required standards or certification scope also cover that version before it is quoted.
Requested drum lengths can be reviewed with the cable schedule. What is practical depends on cable dimensions and weight, total quantity, drum capacity and transport or site-handling limits, so the required lengths should be included with the enquiry.
No single MOQ applies across the entire range. The practical quantity depends on the cable type, size, construction, packing and production conditions. Send the actual cable list and quantities and we can confirm the applicable requirement for those items.
