Halogen-Free XLPE Insulated 0.6/1 kV Power Cable
The halogen-free sheath significantly reduces toxic and corrosive gas emissions during fire exposure. This improves safety for occupants and helps protect electronic equipment and building infrastructure.
Cross-linked polyethylene insulation provides improved dielectric strength and thermal resistance compared with traditional PVC insulation. This supports reliable power transmission in modern building energy systems.
N2XH cables are commonly specified in projects where fire safety and evacuation conditions are important considerations. Their construction supports safe operation in commercial and industrial electrical infrastructure.
| Description | Cross Section m㎡ |
OD of conductor mm | Thickness of Insulation mm | Thickness of Sheath mm | Cable overall diameter mm | Current Capaciy in air A | Alu weight kg/km | Cable weight kg/km |
|---|---|---|---|---|---|---|---|---|
| NA2XY 0.6/1(1.2)kV | 1 x 25 | 6.3 | 0.9 | 1.4 | 11.7 | 136 | 72.5 | 132 |
| NA2XY 0.6/1(1.2)kV | 1 x 35 | 7.1 | 0.9 | 1.4 | 12.5 | 166 | 101.5 | 166 |
| NA2XY 0.6/1(1.2)kV | 1 x 50 | 8.1 | 1 | 1.4 | 13.6 | 205 | 145 | 211 |
| NA2XY 0.6/1(1.2)kV | 1 x 70 | 9.7 | 1.1 | 1.4 | 15.5 | 260 | 203 | 283 |
| NA2XY 0.6/1(1.2)kV | 1 x 95 | 11.4 | 1.1 | 1.5 | 17.4 | 321 | 275.5 | 376 |
| NA2XY 0.6/1(1.2)kV | 1 x 120 | 12.7 | 1.2 | 1.5 | 19 | 376 | 348 | 456 |
| NA2XY 0.6/1(1.2)kV | 1 x 150 | 14.5 | 1.4 | 1.6 | 22 | 431 | 435 | 560 |
| NA2XY 0.6/1(1.2)kV | 1 x 185 | 15.9 | 1.6 | 1.7 | 23.9 | 501 | 536.5 | 697 |
| NA2XY 0.6/1(1.2)kV | 1 x 240 | 18.6 | 1.7 | 1.8 | 27 | 600 | 696 | 878 |
| NA2XY 0.6/1(1.2)kV | 1 x 300 | 20.7 | 1.8 | 1.9 | 29.5 | 696 | 870 | 1073 |
| NA2XY 0.6/1(1.2)kV | 1 x 400 | 23.5 | 2 | 2 | 32.9 | 821 | 1160 | 1347 |
| NA2XY 0.6/1(1.2)kV | 1 x 500 | 26.5 | 2.2 | 2.1 | 36.6 | 971 | 1450 | 1705 |
| NA2XY 0.6/1(1.2)kV | 1 x 630 | 30.2 | 2.4 | 2.2 | 41 | 1151 | 1827 | 2705 |
Download TDS
Yes. Send the exact cable designation and, where possible, the existing datasheet or project specification. We compare conductor material, construction, voltage rating, standards and the requirements that affect the installation before confirming whether an equivalent can be offered.
Send the exact requirement. The website does not represent every possible production combination. We will check whether the construction can be supplied and whether the required standards or certification scope also cover that version before it is quoted.
Requested drum lengths can be reviewed with the cable schedule. What is practical depends on cable dimensions and weight, total quantity, drum capacity and transport or site-handling limits, so the required lengths should be included with the enquiry.
No single MOQ applies across the entire range. The practical quantity depends on the cable type, size, construction, packing and production conditions. Send the actual cable list and quantities and we can confirm the applicable requirement for those items.
