Stäubli Original MC4-Evo 2 is a 1500 V DC photovoltaic connector using MULTILAM contact technology and crimp termination. It supports 2.5 to 10 mm² PV cable configurations with IEC current ratings up to 69 A, while the selected connector variant must still match the actual cable cross-section and outer diameter.
MC4-Evo 2 is rated for DC 1500 V under IEC and UL, making it suitable for modern high-voltage PV string architecture without changing to a different connector family at the 1500 V system level.
IEC ratings increase with the matched PV cable cross-section, reaching 69 A with the specified 10 mm² configuration. This gives designers more current capacity while keeping the connector, contact and cable selection tied to one defined assembly.
The MULTILAM contact system and tin-plated copper contacts provide a connector resistance below 0.2 mΩ. Maintaining that interface depends on correct stripping, crimping, tightening and mating according to the Stäubli assembly instructions.
The mated connector carries IP65/IP68 protection under the specified test condition and is qualified for demanding PV environments. Unmated ends remain IP2X, so storage, transport and installation practice still need to prevent contamination before mating.
Designed for 1500 V rooftop PV, Commercial PV arrays, Utility-scale solar fields and PV extension cable assemblies.
| Nominal cross section mm² | IEC rated voltage DC V | IEC rated current A |
|---|---|---|
| 2.5 | 1500 | 39 |
| 4 | 1500 | 45 |
| 6 | 1500 | 53 |
| 10 | 1500 | 69 |
Connector selection also depends on PV cable outer diameter and the matching Stäubli MC4-Evo 2 crimp contact / cable gland variant. Use the exact Stäubli ordering table for the finished assembly.
Download TDS
Send the exact connector manufacturer and model together with the cable size. Current PV extension options include Stäubli Original MC4 and MC4-EVO 2. Compatibility is checked against the actual connector system; appearance or a general “MC4-compatible” description is not enough.
